10.4 inch monitor

10.4 inch industrial monitor metal case open frame lcd monitor resistive touch






LCD panel( IPS screen)

Panel size

10.4” (4:3)

Native Resolution

800X600

Brightness (cd/m²)

350 cd/m2

Contrast ratio

500:1

View angle

75°/75°/70°/70° (R/L/U/D)

Touch panel

Touchscreen Type

10 points Projected capacitive touch

Touch Interface

USB

Signal Ports

VGA

1×VGA

USB

1xUSB for touch

HDMI

1xHDMI

DVI

1XDVI

OSD

OSD control

Brightness, contrast ratio, auto adjustment, H/V position, language select etc.

Support OS

Windows XP , Windwows /7/8/10 , Linux, Mac OS X, Android, Raspberry Pi ect

Power Supply

External Power Supply

AC 100 - 240V

Working voltage

DC 12V

Power consumption

≤30W

Operating Environment

Temperature Range

operating: -10 to 60°C, storage :-20 to 80°C

Relative humidity

operating: 10% to 90% , storage :5% to 90%

Packing Details

Packing detail

1pcs/box/carton

Accessories

Power adapter, VGA cable,HDMI cable,DVI cable, USB touch cable, Stander optional

Others

Warranty

1 year warranty


Applications

· Automatic system:intelligent self-service terminal, intelligent retail terminal, O2O smart device, robot equipment, etc.
· Public Places: subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums,   museums,convention centers, ticket agencies, HR market, lottery centers;
· Business Organizations: supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy.
· Financial Organizations: Banks, negotiable securities, funds, insurance companies, pawnshops;
· Non-profit Organizations: Telecommunications, post offices, hospital, schools;
· Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers;
· Entertainments: Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course.
